Designed for Class I Division 2 hazardous locations
Intelligence with intent-based networking to the IoT Edge and IOx support
Partner IoT modules for WirelessHART ISA100
Cisco DNA Assurance for network management
802.11ac Wave 1 and 2 capabilities
2x2 MIMO with two spatial streams
Multi- and single-user MIMO
Maximal-Ratio Combining (MRC)
802.11ac beamforming (transmit beamforming)
20- 40- and 80-MHz channels
PHY data rates up to 867 Mbps (80-MHz bandwidth in 5 GHz)
Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
802.11 Dynamic Frequency Selection (DFS)
Cyclic Shift Diversity (CSD) support
802.11n Version 2.0 (and related) capabilities
2x2 MIMO with two spatial streams
Maximal-Ratio Combining (MRC)
20- and 40-MHz channels
PHY data rates up to 300 Mbps (40-MHz bandwidth in 5 GHz)
Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
802.11 Dynamic Frequency Selection (DFS)
Cyclic Shift Diversity (CSD) support
Data rates supported
2.4-GHz radio:
802.11b: 1 2 5.5 11 Mbps
802.11g: 6 9 12 18 24 36 48 54 Mbps
802.11n data rates:
Interfaces
x1 10/100/1000BASE-T autosensing PoE+ In (802.3at)UPOE in
x2 10/100/1000BASE-T autosensing PoE Out (802.3af) PoE+ out (802.3at)
x1 fiber SFP (fiber or electrical)
Management console port (RJ-45)
USB3.0 port
Multicolor system LED port LED
DC power input (IW-6300H-DC-X-K9 IW-6300H-DCW-X-K9)
AC power input (IW-6300H-AC-X-K9)
Reset button
Uplink options
Ethernet SFP and wireless mesh
Dimensions (W x L x H)
IW-6300H-DC-X-K9: 9.7" x 11" x 3.8"
IW-6300H-DCW-X-K9: 9.7" x 11" x 5.6"
IW-6300H-AC-X-K9: 9.7" x 11" x 5.6"
Weight
13.3 lbs (IW-6300H-AC-X-K9), 9.8 lbs (IW-6300H-DC-X-K9),
12.7 lbs (IW-6300H-DCW-X-K9)
Warranty
1 year
IW 6300 Series
IW-6300H-DC-X-K9: Dual-band 802.11a/g/n/ac Wave 2 external antennas 44-57VDC/POE+/UPOE power input
IW-6300H-DCW-X-K9: Dual-band 802.11a/g/n/ac Wave 2 external antennas 10.8-36VDC/POE+/UPOE power input
IW-6300H-AC-X-K9: Dual-band 802.11a/g/n/ac Wave 2 external antennas 110-220VAC/POE+/UPOE power input
Product Details...!
- Four radios: 2.4 GHz (4x4) 5 GHz (8x8 and 4x4) Cisco RF ASIC, and BLE/IoT
- Cisco Flexible Radio Assignment and Cisco CleanAir Technology
- Internal and external antenna
- WiFi 6 certified
- Software: Catalyst 9130 AXI: Cisco Unified Wireless Network Software Release 8.10.x or later
- Cisco IOS XE Software Release 16.12.1 with AP Device Pack or later
- Catalyst 9130AXE: Cisco Unified Wireless Network Software Release 8.10MR1 or later
- Cisco IOS XE Software Release 17.1.1 s or later
- Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
- Cisco 3504 5520 and 8540 Wireless Controllers and Cisco Virtual Wireless Controller
- 802.11n version 2.0 (and related) capabilities
- 4x4 MIMO with four spatial streams
- Maximal Ratio Combining (MRC)
- 802.11n and 802.11a/g
- 20- and 40 MHz channels
- PHY data rates up to 1.5 Gbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: Aggregate MAC Protocol Data Unit (A-MPDU) (transmit and receive) Aggregate MAC Service Data Unit (A-MSDU) (transmit and receive)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
- 802.11ac
- 8x8 downlink MU-MIMO with eight spatial streams
- MRC
- 802.11ac beamforming
- 20- 40- 80- and 160-MHz channels
- PHY data rates up to 6.9 Gbps (160 MHz with 5 GHz)
- Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- WPA3 support
- 802.11ax
- 8x8 uplink/downlink MU-MIMO with eight spatial streams
- Uplink/downlink OFDMA
- TWT
- BSS coloring
- MRC
- 802.11ax beamforming
- 20- 40- 80- and 160-MHz channels
- PHY data rates up to 10 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- WPA3 support
- System memory: 2048 MB DRAM 1024 MB flash
- Interfaces
- 1x 100 1000 2500 5000 Multigigabit Ethernet (RJ-45) – IEEE 802.3az
- Management console port (RJ-45)
- USB 2.0 at 4.5W (enabled via future software)
- Dimensions (W x L x H)
- Access point (without mounting brackets):
- C9130AXI: 8.9 x 8.9 x 1.88 in. (22.6 x 22.6 x 4.8 cm)
- C9130AXE: 9.17 x 9.17 x 1.58 in. (23.3 x 23.3 x 4.0 cm)
- Weight: Cisco Catalyst 9130AXI 3.2 lb. (1.45 kg)
- Cisco Catalyst 9130AXE 3.78 lb. (1.71 kg)
- Warranty: Limited lifetime hardware warranty
Product Details...!
- Four radios: 2.4 GHz (4x4) 5 GHz (4x4) Cisco RF ASIC and BLE/IoT
- Cisco Flexible Radio Assignment and Cisco CleanAir Technology
- Internal and external antenna
- Software
- Cisco Unified Wireless Network Software Release 8.9.x or later
- Cisco IOS XE Software Release 16.11 with AP Device Pack or later
- Supported wireless LAN controllers
- Cisco Catalyst 9800 Series Wireless Controllers
- Cisco 3500 5520 and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
- 802.11n version 2.0 (and related) capabilities
- 4x4 MIMO with four spatial streams
- Maximal Ratio Combining (MRC)
- 802.11n and 802.11a/g beamforming
- 20- and 40-MHz channels
- PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
- 802.11ac
- 4x4 downlink MU-MIMO with four spatial streams
- MRC
- 802.11ac beamforming
- 20- 40- 80- and 160-MHz channels
- PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)
- Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- 802.11ax
- 4x4 downlink MU-MIMO with four spatial streams
- Uplink/downlink OFDMA
- TWT
- BSS coloring
- MRC
- 802.11ax beamforming
- 20- 40- 80- and 160-MHz channels
- PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- Interfaces: 1x 100 1000 2500 Multigigabit Ethernet (RJ-45)IEEE 802.3bz
- Management console port (RJ-45) USB 2.0 3.75W (enabled via future software)
- Indicators: Status LED indicates boot loader status association status operating status boot loader warnings and boot loader errors
- Dimensions (W x L x H)
- Access point (without mounting brackets): C9120I: 8.5 x 8.5 x 1.7 (21.6 x 21.6 x 4.3 cm) C9120E and C9120P: 8.5 x 8.05x 2.0 (21.6 x 21.6 x 5.1 cm)
- Weight: Cisco Catalyst 9120I 2.87 lbs (1.3 kg)
- Cisco Catalyst 9120E/P 3 lbs (1.36 kg)
- System memory: 2048 MB DRAM 1024 MB flash
- Warranty: Limited lifetime hardware warranty
Product Details...!
- Three radios: 2.4GHz (4x4) 5GHz (8x8) and BLE Supports OFDMA and MU-MIMO Internal antenna
- Software: Cisco Unified Wireless Network Software Release 8.9 or later
- Cisco IOS XE Software Release 16.11 or later
- Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
- Cisco 3500 5520 and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
- 802.11n version 2.0 (and related) capabilities
- 8x8 MIMO with four spatial streams for 5 GHz band
- 4x4 MIMO with four spatial streams for 2.4 GHz band
- Maximal Ratio Combining (MRC)
- 20- and 40-MHz channels
- PHY data rates up to 600 Mbps (40 MHz with 5 GHz)
- Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
- Cyclic Shift Diversity (CSD) support
- 802.11ac
- 8x8 downlink MU-MIMO with eight spatial streams
- MRC
- 802.11ac beamforming
- 20- 40- 80 and 160 MHz channels
- PHY data rates up to 3.5 Gbps at 5 GHz
- Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
- CSD support
- 160 MHz support only on 4 spatial stream
- 802.11ax
- 8x8 MIMO with eight spatial streams for 5-GHz band
- 4x4 MIMO with four spatial streams for 2.4-GHz band
- Downlink OFDMA
- TWT
- MRC
- 802.11ax beamforming
- 20- 40- 80 and 160 MHz channels
- PHY data rates up to 5 Gbps at 5 GHz
- Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
- CSD support
- Integrated antenna: 2.4 GHz peak gain 4 dBi internal antenna omnidirectional in azimuth
- 5 GHz peak gain 6 dBi internal antenna omnidirectional in azimuth
- Interfaces: 1x 100 1000 2500 5000 Multigigabit Ethernet (RJ-45)IEEE 802.3bz
- Management console port (RJ-45)
- USB 2.0 with up to 4.5W (enabled via future software)
- Indicators: Status LED indicates boot loader status association status operating status boot loader warnings and boot loader errors
- Dimensions (W x L x H)
- Access point (without mounting bracket and mounting features): 8.70 x 8.70 x 1.94 in. (22 x 22 x 4.93 cm)
- Access point (without mounting bracket): 8.70 x 8.70 x 2.19 in. (22 x 22 x 5.56 cm)
- Weight: 3.02 lb (1.4 kg)
- System memory: 2048 MB DRAM 1024 MB flash
- Warranty: Limited lifetime hardware warranty
Product Details...!
- Three radios: 2.4GHz (4x4) 5GHz (4x4) and BLE Supports OFDMA and MU-MIMO Internal and external antenna
- Software: Cisco Unified Wireless Network Software Release 8.9 or later
- Cisco IOS XE Software Release 16.11 or later
- Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
- Cisco 3500 5520 and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
- 802.11n version 2.0 (and related) capabilities
- 4x4 MIMO with four spatial streams
- Maximal Ratio Combining (MRC)
- 802.11n and 802.11a/g beamforming
- 20- and 40-MHz channels
- PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
- 802.11ac
- 4x4 downlink MU-MIMO with four spatial streams
- MRC
- 802.11ac beamforming
- 20- 40- 80- and 160-MHz channels
- PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)
- Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- 802.11ax
- 4x4 downlink MU-MIMO with four spatial streams
- Uplink/downlink OFDMA
- TWT
- BSS coloring
- MRC
- 802.11ax beamforming
- 20- 40- 80- and 160-MHz channels
- PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive) A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- Integrated antenna: 2.4 GHz peak gain 3 dBi internal antenna omnidirectional in azimuth
- 5 GHz peak gain 4 dBi internal antenna omnidirectional in azimuth
- External antenna (sold separately)
- Cisco Catalyst 9115AXE Access Points are certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)
- Cisco offers the industry's broadest selection of antennas delivering optimal coverage for a variety of deployment scenarios
- Interfaces: 1x 100 1000 2500 Multigigabit Ethernet (RJ-45) – IEEE 802.3bz
- Management console port (RJ-45) USB 2.0 (enabled via future software)
- Indicators: Status LED indicates boot loader status association status operating status boot loader warnings and boot loader errors
- Dimensions (W x L x H)
- Access point (without mounting brackets): C9115I: 8.0 x 8.0 x 1.5 in. (20.3 x 20.3 x 3.8 cm) C9115E: 8.0 x 8.0 x 1.7 in. (20.3 x 20.3 x 4.3 cm)
- Weight: Cisco Catalyst 9115AXI 1.98 lb (0.9 kg)
- Cisco Catalyst 9115AXE 2.43 lb (1.1 kg)
- System memory: 2048 MB DRAM 1024 MB flash
- Warranty: Limited lifetime hardware warranty
Product Details...!
- Aironet 1542I
- Semi omnidirectional antenna
- 802.11ac Wave 2 support
- MU MIMO 2x2 2 spatial streams
- Flexible deployment with Mobility Express
- as traditional APs and in mesh networks
- Aironet 1542D
- Directional antenna
- 802.11ac Wave 2 support
- MU-MIMO 2x2 2 spatial streams
- Flexible deployment with Mobility Express
- as traditional APs and in mesh networks
- 802.11ac Wave 1 and 2 capabilities
- 1542I/D: 2 x 2 MIMO with two spatial streams
- Multiuser and single user MIMO
- Maximal Ratio Combining (MRC)
- 802.11ac beamforming (transmit beamforming)
- 20- 40- and 80-MHz channels
- PHY data rates up to 867 Mbps (80 MHz in 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
- 802.11n (and related) capabilities
- 1542I/D: 2 x 2 MIMO with two spatial streams
- MRC
- 20- and 40-MHz channels (40 MHz in 5 GHz)
- PHY data rates up to 300 Mbps
- Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
- 802.11 DFS
- CSD support
- Data rates supported: 802.11a: 6 9 12 18 24 36 48 and 54 Mbps
- 802.11b/g: 1 2 5.5 6 9 11 12 18 24 36 48 and 54 Mbps
- 802.11n data rates on 2.4 and 5 GHz
- Maximum conducted transmit power
- 1542I
- 2.4 GHz: 27 dBm with 2 antennas
- 5 GHz: 25 dBm with 2 antennas
- 1542D
- 2.4 GHz: 27 dBm with 2 antennas
- 5 GHz: 25 dBm with 2 antennas
- Interfaces
- WAN port 10/100/1000BASE-T Ethernet autosensing (RJ-45) PoE in
- Management console port (RJ-45)
- Multicolor LED/Reset button
- Wireless Access
- 802.11i Wi-Fi Protected Access 2 (WPA2) and WPA
- 802.1X authentication including Extensible Authentication Protocol (EAP) and Protected EAP (EAP -PEAP), EAP Transport Layer Security (EAP-TLS) EAP-Tunneled TLS
- (EAP-TTLS) EAP-Subscriber Identity Module (EAP-SIM) and Cisco LEAP
- VPN pass-through
- IP Security (IPsec)
- Layer 2 Tunneling Protocol (L2TP)
- MAC address filtering
- Uplink options: Ethernet and wireless mesh
- Dimensions(L x W x H):
- 1542I/D: 7.9 x 5.9 x 2.4 in.(20 x 15 x 6.1 cm)
- Weight
- 1542I/D: 2.75 lb (1.25 kg)
- Warranty: 1 year limited hardware warranty
Product Details...!
- Aironet 1562I
- 802.11ac Wave 2 support
- 3x3 MU-MIMO 3 spatial streams
- Internal antenna
- Aironet 1562E
- 802.11ac Wave 2 support
- 2x2 MU-MIMO 2 spatial streams
- Flexible antenna ports
- External antenna
- Aironet 1562D
- 802.11ac Wave 2 support
- 2x2 MU-MIMO 2 spatial streams
- Directional antenna
- 802.11ac Wave 1 and 2 capabilities
- 1562I: 3 x 3 MIMO with three spatial streams
- 1562E/D 2 x 2 MIMO with two spatial streams
- Multi and single user MIMO
- Maximal Ratio Combining (MRC)
- 802.11ac beamforming (transmit beamforming)
- 20- 40- and 80 MHz channels
- PHY data rates up to 1.3 Gbps (80 MHz in 5 GHz)
- Packet aggregation: A MPDU (Tx/Rx) and A MSDU (Tx/Rx)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
- 802.11n (and related) capabilities
- 1562I: 3 x 3 MIMO with three spatial streams
- 1562E/D: 2 x 2 MIMO with two spatial streams
- MRC
- 20- and 40 MHz channels
- PHY data rates up to 450 Mbps
- Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
- 802.11 DFS
- CSD support
- Data rates supported
- 802.11a: 6 9 12 18 24 36 48 and 54 Mbps
- 802.11b/g: 1 2 5.5 6 9 11 12 18 24 36 48 and 54 Mbps
- Interfaces
- WAN port 10/100/1000BASE-T Ethernet autosensing (RJ-45) PoE in
- SFP port (fiber or electrical)
- Management console port (RJ-45)
- Multicolor LED
- DC power input
- Reset button
- Uplink options
- Ethernet SFP and wireless mesh (future availability)
- Dimensions(L x W x D)
- 1562I: 9.0 x 6.8 x 3.9 in (22.9 x 17.1 x 9.8 cm)
- 1562D: 9.0 x 6.8 x 4.3 in (22.9 x 17.1 x 10.9 cm)
- 1562E:: 9.0 x 6.8 x 3.9 in (22.9 x 17.1 x 9.8 cm)
- Weight
- 1562I: 5.6 lb (2.5 kg)
- 1562D: 5.7 lb (2.6 kg)
- 1562E: 5.6 lb (2.5 kg)
- Warranty: 1 year limited hardware warranty
Product Details...!
- 802.11ac support
- 4x4 MIMO 3 spatial streams
- Flexible antenna port
- 802.11n Version 2.0 capabilities
- 4x4 MIMO with three spatial streams (3SS)
- Maximal Ratio Combining (MRC)
- 802.11n and 802.11a/g Beamforming
- 20- and 40-MHz channels
- PHY data rates up to 450 Mbps (40 MHz with 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx) A-MSDU (Tx/Rx)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
- 802.11ac Wave 1 capabilities
- 4x4 MIMO with three spatial streams (3SS)
- Maximum Ratio Combining (MRC)
- 802.11ac Beamforming
- 20- 40- and 80-MHz channels
- PHY data rates up to 1.3 Gbps (80 MHz with 5 GHz)
- Packet aggregation: A-MPDU (Tx/Rx) A-MSDU (Tx/Rx)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
- Data Rates Supported: 2.4 GHz - 802.11b/g: 1 2 5.5 6 9 11 12 18 24 36 48 and 54 Mbps
- Interface
- WAN port 10/100/1000BASE T Ethernet autosensing (RJ-45)
- LAN port 10/100/1000BASE T Ethernet autosensing (RJ-45)
- Fiber SFP
- Cable modem: NA-DOCSIS3.0/Euro-DOCSIS3.0/Japan-DOCSIS3.0 (8x4 16x8 or 24x8)
- Management console port (RJ-45)
- Four multicolor LEDs
- Reset button
- Uplink options
- 1572EAC Ethernet Fiber SFP, Wireless Mesh
- 1572IC Ethernet Fiber SFP, Wireless Mesh Cable Modem
- 1572EC Ethernet Fiber SFP, Wireless Mesh Cable Modem
- Dimensions (L x W x D): 1572EAC / 1572EC 11.8 x 7.9 x 6.3 in. (30.0 x 20.1 x 16.0 cm)
- 1572IC 11.8 x 7.9 x 7.9 in. (30.0 x 20.1 x 20.1 cm)
- Weight
- 1572EAC/1572EC 13.5 lbs (6.1 kg)
- 1572IC 11.5 lbs (5.2 kg)
- Pole mounting Kit 1 (PMK1):2.2 lbs (1.0 kg)
- Pole mounting Kit 2 (PMK2):4.4 lbs (2.0 kg)
- Pole mounting Kit 3 (PMK3):6.1 lbs (2.8 kg)
- Cable strand mounting bracket 1 (SMK1): 0.3 lbs (0.2 kg)
- Cable strand mounting bracket 2 (SMK2): 0.7 lbs (0.3 kg)
- Cable strand mounting bracket 2 (SMK3): 1.2 lbs (0.5 kg)
- Warranty: 1 year limited Hardware warranty
Product Details...!
Embed resilient Cisco WiFi into your hardware.
Extend intent-based networking to your solutions .
IOx support for intelligence at the edge.
Cisco DNA Assurance for worry-free network management.
Radio type
2.4 GHz: 802.11b/g/n 2x2 MIMO 2 spatial streams
5 GHz: 802.11a/n/ac 2x2 MIMO 2 spatial streams
802.11ac Wave 2 capabilities
2x2 MIMO with two spatial streams
Multi- and single-user MIMO
Maximal-Ratio Combining (MRC)
802.11ac beamforming (transmit beamforming)
20- 40- and 80-MHz channels
PHY data rates up to 867 Mbps (80-MHz bandwidth in 5 GHz)
Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
802.11 Dynamic Frequency Selection (DFS)
Cyclic Shift Diversity (CSD) support
802.11n Version 2.0 (and related) capabilities
2x2 MIMO with two spatial streams
Maximal-Ratio Combining (MRC)
20- and 40-MHz channels
PHY data rates up to 300 Mbps (40-MHz bandwidth in 5 GHz)
Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
802.11 Dynamic Frequency Selection (DFS)
Cyclic Shift Diversity (CSD) support
Data rates supported
2.4-GHz radio:
802.11b: 1 2 5.5 11 Mbps
802.11g: 6 9 12 18 24 36 48 54 Mbps
802.11n data rates:
Interfaces
x1 10/100/1000BASE-T auto-sensing PoE+ in (802.3at)Cisco Universal Power over Ethernet (UPOE) in
x2 10/100/1000BASE-T auto-sensing PoE out (802.3af) PoE+ out (802.3at)
x1 fiber SFP (fiber or electrical)
Management console port (RJ-45)
USB 3.0 port
Multicolor system LED port LED
DC power input
Reset button
Uplink options
Ethernet SFP and wireless mesh
Antennas :Dual band
PoE output : 35.3 W total
Maximum 30W per PSE port
USB interface
USB 2.0 / USB 3.0 supported
Dimensions (H x W x L)
8.5 in. x 7.55 in. x 1.9 in.
Weight
3.1 lbs.
Warranty
1 year
Product Details...!
Industrial outdoor 802.11ac wireless.
Designed and certified for extreme environments.
Rail - rolling stock shock and vibration certified.
Chipset with best-in-class RF architecture.
Software
Cisco Unified Wireless Network Software Release with AireOS Wireless Controllers:
8.0.120.0 or later for the Cisco IW3700 Series Access Point
Cisco IOS Software Release
15.3(3)JA5 or later for the Cisco IW3700 Series Access Point
802.11ac Wave 1 capabilities
4 x 4 MIMO with 3 spatial streams
Maximal-Ratio Combining (MRC)
802.11ac beamforming
20- 40- and 80-MHz channels
PHY data rates up to 1.3 Gbps (80 MHz with 5 GHz)
Packet aggregation: A-MPDU (Tx/Rx) A-MSDU (Tx/Rx)
802.11 Dynamic Frequency Selection (DFS)
Cyclic Shift Diversity (CSD) support
802.11n version 2.0 (and related) capabilities
4 x 4 MIMO with 3 spatial streams
Maximal-Ratio Combining (MRC)
802.11n and 802.11a/g beamforming
20- and 40-MHz channels
PHY data rates up to 450 Mbps (40 MHz with 5 GHz)
Packet aggregation: A-MPDU (Tx/Rx) A-MSDU (Tx/Rx)
802.11 Dynamic Frequency Selection (DFS)
Cyclic Shift Diversity (CSD) support
Data rates supported
802.11a: 6 9 12 18 24 36 48 and 54 Mbps
802.11g: 1 2 5.5 6 9 11 12 18 24 36 48 and 54 Mbps
Interfaces
10/100/1000BASE-T autosensing (M12 8P female connector with X-coding per IEC 61076-2) PoE In (802.3af) PoE+ In (802.3at)
10/100/1000BASE-T autosensing (M12 8P female connector with X-coding per IEC 61076-2) PoE Out (802.3af)
Management console port (serial with RJ-45 connector)
Indicators
Status LED indicates boot loader status association status operating status boot loader warnings boot loader errors
System memory
512 MB DRAM
64 MB flash
Dimensions (W x L x H)
Access point (not including connectors): 11.3 x 8.0 x 2.3 in (28.7 x 20.3 x 5.9 cm)
Volume: 148 cubic inches (2.4 liters)
Weight
6.7 lb (3.0 kg)
Warranty
5-year limited hardware warranty
Product Details...!
- Brand : Cisco Systems
- Product Name : Cisco Business 150AX Wi-Fi 6 2x2 Access Point 1 GbE Port - Ceiling Mount
- Product Type : Wireless Access Point
- Network Band : Dual Band
- Frequency Band : 2.40 GHz , 5 GHz
- Antenna Form Factor : Internal
- Wireless LAN Standard : IEEE 802.11ax
- Ethernet Technology : Gigabit Ethernet
- Number of Network (RJ-45) Ports : 1
- PoE (RJ-45) Port : Yes
- Form Factor : Ceiling Mountable , Wall Mountable
- Dynamic VLAN or per port
- Traffic locally switched or tunneled back to Primary AP
- 1 GB DRAM, 256 MB flash
- 1GHz quad core processor
- AC Power Supply with region specific wall plug
Product Details...!
- Device Interfaces : 802.11 b/g/n wireless, 10/100 Mbps PoE LAN port
- LED : Power/Status
- Standards : IEEE 802.11b/g/n, IEEE 802.3u/ab/af
- Wireless Frequency Range : 2.4 GHz band: 2.4 GHz to 2.4835 GHz
- Security : WPA-Personal, WPA-Enterprise
- Antennas : Two internal 3 dBi for 2.4 GHz
- Maximum Output Power : 20 dbm for 2.4GHz as per EU / CE Starndards
- Dimensions :129 x 129 x 29 mm
- Warranty : 3 Years
Product Details...!
- Brand : D-Link
- Model : DAP-X2810
- Wireless Speed : Up to 1800 Mbps (2.4 GHz + 5 GHz)
- Antenna Type : Two Internal Antennas
- LAN : 1 (10/100/1000)
- MU-MIMO : Yes
- Wi-Fi 6 AX1800, up to 1.8 Gbps1
- Dual-band, 2x2 MIMO, band-steering & airtime fairness
- Free-to-download Nuclias Connect software & app
- Flexible installation with PoE
- Customisable captive portal
- D-Link Limited Lifetime Warranty
Product Details...!
- Processor : 1 GHz Dual-Core CPU
- Faster Connections : Wi-Fi 6 speeds up to 3,000 Mbps—2,402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz
- Connect More Devices : OFDMA and MU-MIMO technology quadruple capacity to enable simultaneous transmission to more devices
- Boosted Seamless Coverage : Achieve seamless whole-home coverage with a clearer and stronger whole-home Wi-Fi signal generated by Wi-Fi 6.
- Ultra-Low Latency : Greater reduction in latency enables more responsive gaming and video chatting.
- One Unified Network : Multiple units form a whole-home network that auto-selects the best connection as you move around your home.
- Total Security : WPA3 encryption and TP-Link HomeShield provide personalized features, including Parental Controls, Antivirus, and Quality of Service (QoS) to ensure a safer online experience.
- TP-Link HomeShield : Keeps your home network safe with cutting-edge features for network and IoT protection.
- Setup Made Easier Than Ever : The Deco app walks you through the setup step-by-step.
- Working Modes : Router Mode , Access Point Mode
Product Details...!
- Brand : Netgear
- Model Name : Netgear WAC 720
- Physical Specifications : Physical Dimensions (W x D x H): 197 x 197 x 40mm (7.76 x 7.76 x 1.57in)
- Weight : 726g (1.6lb)
- Color : White
- Standards : IEEE 802.11ac Wave 1 standard
- Application : WiFi
- Power Supply : POE
- Range : 1200 Mtr.
- LAN Ports : 1
- Business class with superior 802.11ac performance (up to 1.2 Gbps)
- 2 x 2 (Transmit x Receive) with 2 streams of data for 2.4 GHz (300 Mbps) and 5 GHz (867 Mbps) of reliable data delivery 802.11ac beamforming to improve range, minimizes interference while maximizing data rates.
- Internal antennas for maximum RF performance
Product Details...!
- Brand : D-Link
- Model : DAP 2610
- PoE Mode : 802.3af/802.3at
- Interface : One 10/100 /1000 Ethernet port
- Dimensions : 170 x 170 x 28 mm
- Environment : Indoor
- 2.4GHz Speed : 400Mbps
- 5GHz Speed : 867Mbps
- MU-MIMO and Tx beamforming : Yes
- Maximum Output Power : 2.4GHz:23dBm 5GHz:23dBm
- Mounting : Wall/Ceiling
Product Details...!
- Brand : D-Link
- Model : DAP 2682
- PoE Mode : 802.3at
- Interface : Two 10/100 /1000 Ethernet port (PoE Supported)
- Dimensions : 190 x 190 x 43.7 mm
- Environment : Indoor
- 2.4GHz Speed : 600 Mbps
- 5GHz Speed : 1700 Mbps
- MU-MIMO and Tx beamforming : Yes
- Maximum Output Power : 2.4 GHz :28 dBm / 5 GHz : 28 dBm
- Mounting : Wall/Ceiling
Product Details...!
- Brand : D-Link
- Model : DAP 3666
- PoE Mode : 802.3af
- Interface : Two 10/100 /1000 Ethernet ports (One supports PoE)
- Dimensions : 277 x 240 x50 mm
- Environment : Outdoor
- 24GHz Speed : 300Mbps
- 5GHz Speed : 866Mbps
- MU-MIMO and Tx beamforming : Yes
- Maximum Output Power : 2.4GHz:26dBm 5GHz:26dBm
- Mounting : Wall/Pole
Product Details...!
- Brand : D-Link
- Model : DAP-X2850
- Product Description : Nuclias Connect AX3600 Access Point
- LAN : 1 (10/100/1000)? 1 (10/100/1000/2500)
- Ports : Two LAN ports (2.5 Gbps and 1 Gbps) offer expansive backhaul up to wired network, eliminating bottlenecks at the AP
- Wireless Speed : Up to 3600 Mbps (2.4 GHz + 5 GHz)
- Support : Power of Ethernet 802.3at means less wires, for cleaner and easier deployment
- Antenna Type : Four internal antennas
- MU-MIMO : Yes
- D-Link Wi-Fi : N/A
- Voice Control Support (Amazon Alexa / Google Assistant) : N/A
Product Details...!
- Brand : D-Link
- Model : DAP-X1230P
- PoE Mode : 802.3at
- Interface : 1 x 10/100/1000 Mbps Ethernet Port
- Dimensions : 170 x 170 x 28 mm
- Environment : Indoor
- 2.4GHz Speed : 575 Mbps
- 5GHz Speed : 1200 Mbps
- MU-MIMO and Tx beamforming : Yes
- Maximum Output Power : 2.4G Hz :23 dBm / 5 GHz : 22 dBm
- Mounting : Wall/Ceiling
Product Details...!
- Brand : D-Link
- Model : DAP-X2830P
- PoE Mode : 802.3at
- Interface : 1 x 10/100/1000/2500 Mbps Ethernet Port / 1 x 10/100/1000 Mbps Ethernet Port
- Dimensions : 22.45 x 22.39 x 5 cm (8.83 x 8.81 x 1.97 in)
- Environment : Indoor
- 2.4GHz Speed : 1147 Mbps
- 5GHz Speed : 2402 Mbps
- MU-MIMO and Tx beamforming : Yes
- Maximum Output Power : 2.4G Hz :20 dBm / 5 GHz : 20 dBm
- Mounting : Wall/Ceiling
Product Details...!
